Fans For Heaters YB10025mm
General Specifications
Material ---------- Frame:Plastics PBT (Flammability:UL94V-0)
Impeller:Plastics PBT (Flammability:UL94V-0)
Lead Wire -------- + Red - Black (Sensor) Yellow (Control) Brown
Life time -----------50000 Hours Ball bearing
Storage Temperatur--- -25℃ ~ +80℃（Non-comdensing）
Bearing Type----- Ball Bearings
Speed Range----- ±5%
Part Numbering System
YB10025H12D- R 1
1:Waterproof level:0=IP42,1=IP55,2=IP68
R:Sensor: 0=no,R=RD sensor ,F=FG sensor ,P=PWM sensor ,T=Temperature sensor
D:Bearing: S=sleeve bearing, D=ball bearing
Fans for heaters YB10025mm serise ( Mass: g)
| Model No. | Rated Voltage | Operating Voltage | Rated Current | Rated Input | Speed | Maximum Air Flow | Max.Static | Pressure | Noise | |
| VDC | VDC | AMP | Watt | R.P.M | M3/min | CFM | PA | IN H2O | dB-A | |
| YB10025L05 | 5 | 4.0-6.0 | 0.5 | 2.5 | 2600 | 0.65 | 21.4 | 15.6 | 0.68 | 32.5 |
| YB10025L12 | 12 | 6.2-15.8 | 0.3 | 3.6 | 3000 | 0.75 | 26.4 | 20.4 | 0.79 | 35.5 |
| YB10025M12 | 0.38 | 4.56 | 3500 | 0.98 | 37.3 | 24.8 | 0.98 | 41.5 | ||
| YB10025H12 | 0.48 | 5.76 | 4100 | 1.28 | 45.2 | 29.2 | 1.17 | 46.5 | ||
| YB10025X12 | 0.65 | 7.8 | 4600 | 1.42 | 49.6 | 33.5 | 1.32 | 51.5 | ||
| YB10025Y12 | 0.8 | 9.6 | 5100 | 1.54 | 54.5 | 38.6 | 1.51 | 56.5 | ||
| YB10025H24 | 24 | 13.2-28.8 | 0.24 | 5.8 | 4100 | 1.28 | 45.2 | 29.2 | 1.17 | 46.5 |
| YB10025H48 | 48 | 32.0-54.0 | 0.12 | 5.8 | 4100 | 1.28 | 45.2 | 29.2 | 1.17 | 46.5 |
Dimensions of fans for heaters
Air Flow-Static e Pressure Characteristics of fans for heaters
Our products
1. Selected high-quality materials, roller bearings, pure copper motors, high-quality wire
2. High strength and toughness plastic fan blade, one-time injection molding, long service life, not easy to deform and fracture, large air volume, low wind resistance and low noise
3. Advanced spraying process, soft and bright color, lasting
4. Support 12v24v48v, automatic restart, reverse connection protection, speed regulation, waterproof alarm monitoring and other functions, customizable
Other Similar Products
8038mm 9225mm 6015 blower fan
industrial centrifugal blower fan cross flow fan/tangential blower surge protective device
Common Problem
1. How about the caliber of the goods?
It uses a high-grade frame, fan blade, and bearing system, which has a longer lifespan and superior quality, and is primarily used in medium- and high-end product lines. A national inspection-free product certification has been received by several models.
2. What are the product's benefits?
Years of R&D technology development offer superior technical assistance and more thoughtful service. The air volume is greater, the service life is longer, the usage is simpler, the models and functions are extensive, the customization is supported, and the diversity satisfies the demands while using less power than competing goods.
3.How to improve the cooling efficiency of the fan
The radiator surface is sprayed with Liwang 8400 nanometer carbon powder heat dissipating material. After the special material is discharged, the heat dissipation efficiency of the radiator can be effectively improved by more than 15%, up to 25%;
