120 X 120 X 38mm Fan
The ac axial fan 120mm ,especially 120×120×38 mm ac axial fan 115v 220v we produce is high speed and superior quality ,we provide various kinds of sizes in order to meet the requirements of customer .
120 x 120 x 38mm fan
General Specifications
● Material：Aluminum Housing, Plastic Impeller
● Bearings：Maintenance-Free Ball Bearings
● Motor Type：AC Shaded-pole Motor
● Connection：Terminals or Lead wire
● Dielectric Strength：1800 VAC for 1 Sec.
● Insulation Resistance：100 MΩmin.@500VDC
● Operating Temperature：-30 C to +75 C
● Type of Protection：Insulation Class B
● Safety：Impedance Protected
● Plastic Impeller
● Weight : 530g
● Rohs Compliance
120×120×38 mm ac axial fan ( Mass: 530 g)
Dimensions of 120×120×38 mm ac axial fan
