7025 DC Axial Cooling Fan

70x70x25mm

*Airflow: 25.0~49.0 CFM
*Static Pressure: 3.0~10.06 mm-H2O
*Blade / Housing:
  Plastic Material UL 94V-0 P.B.T.
*Lead Wire: UL1007 #24 AWG
*Weight: 82.0

• Bearing System -----2 Ball Bearing

• Life Expectancy----Ball 70000hrs@ 25 ℃

• Frame--------------- --Thermoplastic PBT+30% GF, UL94-V0

• Impeller------------- - Thermoplastic PBT+15% GF, UL94-V0

• Lead Wire---------- --UL 1007, AWG 24, 270±10mm, Red(+), Black(-)

• Protection---------- -Locked rotor protection

• IP Grade ---------- ---Optional

The most widely used is to blow downward with an axial flow fan. The reason why it is so popular is that the overall effect is good and the cost is low. In addition, the direction of the axial flow fan is reversed and turned into an upward-drawing type, which seems to be more and more common.
