1751 DC 24V Axial Fan Low Noise For Wending Machine172*150mm 185CFM Brushless Motor Fan

• Material : Aluminum Housing, Plastic Impeller

• Bearings : Maintenance-Free Ball Bearings

• Motor Type : DC Permanent Magnet Brushless

• Connection : Terminals or Lead wire

• Dielectric Strength : 500 VAC for 1 Min.

• Insulation Resistance : 100 MΩ min.@500VDC

• Operating Temperature : -10 ℃ to +70 ℃

• Type of Protection Insulation Class B, IP54

• Safety ： Locked Rotor Protection and Polarity Protection

• Option ： RD, FG, PWM/ Voltage( 0-10 VDC),PWM/Duty(Over 1kHz from 5VDC to 48VDC)

Plastic Impeller

Weight : 840g

Rohs Compliance

Our product range is complete, excellent quality and top performance

Our products have undergone various tests and have passed through TUV, CE, RoHS, UL and other relating authoritative certification.

AMR enjoys strong technical and quality advantages in the industry.

Efficient communication with customers, better understanding and quick response to customer needs.
